Adjusting Drawer Panels - Moving Panels in Different Directions

Instructions for Adjusting Drawer Panels

Adjusting drawer panels is a simple task that can be done in a few easy steps. Sometimes, drawer panels can shift out of alignment due to regular use or from transportation of the furniture. The good news is, with the right tools, you can quickly and easily adjust them to the desired position.

Moving Panels to the Right - R:

1. Open the drawer.
2. Remove the covers located on either side of the side panel.
3. Insert the tool into position A.
4. Turn towards the right (R).
5. Adjust the panel to the right.

Moving Panels Upwards - U:

1. Open the drawer.
2. Remove the covers located on either side of the side panel.
3. Loosen the locking screw C.
4. Insert the tool into position B.
5. Turn anti-clockwise on the left side and clockwise on the right side.

Moving Panels to the Left - L:

1. Open the drawer.
2. Remove the covers located on either side of the side panel.
3. Insert the tool into position A.
4. Turn towards the left (L).
5. Adjust the panel to the left.

Moving Panels Downwards - D:

1. Open the drawer.
2. Remove the covers located on either side of the side panel.
3. Loosen the locking screw C.
4. Insert the tool into position B.
5. Turn clockwise on the left side and anti-clockwise on the right side.

In conclusion, adjusting drawer panels is a straightforward process that can be done with the right tools and a little bit of patience. However, it is important to note that if you are unsure or uncomfortable performing this task, it is recommended that you seek the help of a qualified technician or handy person.
